Edge service

A small service that runs next to the capture device. It talks to the scanner, gives your web application a simple local REST API for capture and live preview, keeps an encrypted local person database and synchronises it with the Cloud Iris API. Enrolment and matching keep working when the network is down.

Supported devices:

Runs on Windows and Linux with Java 11 or newer.

Installation

  1. Install JDK 11 or newer and make sure java -version reports 11+.
  2. Install the device driver from the scanner vendor.
  3. Unpack the service build into a folder, for example C:\iriscan or /opt/iriscan.
  4. Start it with start.bat (Windows) or ./start (Linux). To run it as a system service use install-service.bat or install-service.sh; on Linux this installs a systemd unit named iriscan.

The service listens on http://localhost:8080. Builds are provided to customers on request.

The local database is an embedded H2 file encrypted with AES and unlocked with the device ID and key issued with your tenant.

Capture API

All responses carry "status": "success" or "status": "error".

Method Path What it does
POST /1.0/initialize Opens the scanner and starts the preview stream
GET /1.0/stream Live preview as MJPEG (multipart/x-mixed-replace)
POST /1.0/capture Captures a sample, returns captureIds
GET /1.0/samplequality Quality of the last capture
POST /1.0/download/image Last captured image as base64 JPEG in sensorData
GET /1.0/deviceinfo Device properties as key/value pairs
POST /1.0/initialize
{ "status": "success", "cameraModality": "monocular", "streamUrls": ["stream"] }

GET /1.0/samplequality
{ "status": "success", "quality": { "submodality": "iris", "totalScore": 87, "usableAreaScore": 92 } }

A typical page puts <img src="http://localhost:8080/1.0/stream"> in front of the user, polls samplequality while the subject positions the eye, calls capture when the score is good enough and then download/image.

Local person API

The same person operations as the Cloud Iris API are served locally under /tenant-api/persons: create, update, delete, query, 1:N find and 1:1 verify.

Every new person is encrypted with the device key and pushed to the cloud tenant over a persistent RSocket connection. Records enrolled while the site was offline are sent when the connection comes back, so enrolment and verification never wait for the network.
